Powerful. Configurable. Versatile...
The NEW GENERATION Freedom SW series represents highly sophisticated and advanced inverter/ chargers available in 3000 W with 150 A charger and 2000 W with 100 A charger models.
The second generation 2000 watt model has been completely redesigned to include many of the same great features found in its high power counterpart.A key feature enhancement is ?Generator Support Mode? which enables the Freedom SW to supplement a generator when AC loads exceed the generator?s capacity. The new generation models also feature improved AC transfer/AC input detection time, providing the ability to transfer AC loads to batteries in less than 10 milliseconds when the incoming grid or generator power is lost. Connected loads are almost unable to feel the power transition due to this quick transfer time. Both models are approved to UL458 with marine supplement, CSA, ABYC and FCC, Class B requirements.
NEW - PARALLEL AND SERIES STACKING
Parallel stacking enables the Freedom SW inverter/chargers to double the AC output in inverter mode. Series stacking enables the Freedom SW inverter/chargers to generate 120/240 V split phase output
AC source must be split phase, requires Stacking Cable (part# 808-9005)
ApplicationDesigned for a variety of mobile applications such as commercial, emergency and recreational vehicles, marine vessels, construction and military equipment.
*When used with the remote panel
**Sold separately
Protection Features
Specifications
| Inverter Specifications | Freedom SW 2012 - 815-2012 | Freedom SW 3012 - 815-3012 |
| Output power (continuous @ 40 C) | 2000W | 3000W |
| Surge rating (5 seconds) | 4000W | 6000W |
| Peak output current | 55A | 80A |
| Output frequency | 60Hz +/- 0.2hz | 60Hz +/- 0.2hz |
| Output voltage | 120 Vac | 120 Vac |
| Output wave form | Pure sine wave | Pure sine wave |
| Optimal efficiency | 90% | 90% |
| No-load power draw (inverting) | 3Adc | 3Adc |
| Input DC voltage range | 10 - 16Vdc | 10 - 16Vdc |
| AC connections | Single phase in/out | Split phase in/dual out, Dual in / dual out |
| Charger Specifications | ||
| output current (continuous @ 25 C) | 100A | 150A |
| output voltage | 12Vdc | 12Vdc |
| Output voltage range | 3 - 16Vdc | 3 - 16Vdc |
| Charge control | 3 stage with manual equalize | 3 stage with manual equalize |
| Charge temperature compensation | Remote battery sensor (included) | Remote battery sensor (included) |
| Optimal efficiency | >85% | >85% |
| AC input power factor (maximum charge) | 0.98 typical | 0.98 typical |
| Input current (for maximum charging) | 16A rms nominal | 24A rms nominal |
| Input AC voltage | 120vac | 120vac |
| Input AC voltage range | 85-140Vac | 85-140 Vac |
| Dead battery charge | >3Vdc | >3Vdc |
| General Specifications | ||
| Compatible battery types | Flooded/Gel/AGM | Flooded/Gel/AGM |
| Tranfer relay rating | 1 leg 30A | 2 legs 30A each |
| Transfer time ( AC to inverter and Inverter to AC) | < 20ms | < 20ms |
| Optimal operating temperature range | -4°F to 140°F | -4°F to 140°F |
| Storage ambient temperature range | -40°F to 185°F | -40°F to 185°F |
| Unit Dimension | 7.75" x 13.5" x 15.25" | 7.75" x 13.5" x 15.25" |
| Unit Weight | 60.5lbs | 73.7lbs |
| Warranty | 2 years | 2 years |
