FLIR AX8 Thermal Monitoring Camera
Model: E70321Gain an entirely new view of your vessel’s mechanical system with the new FLIR AX8 thermal monitoring camera. Combining thermal and visible cameras in a small, affordable package, the AX8 integrates with Raymarine multifunction displays (MFDs) and sends audible and visual alerts when the temperature of machine parts rise above preset thresholds.
Keep a watchful eye on such critical equipment as engines, exhaust manifolds, and shaft bearings and spot problems before they leave you stranded on the water. And FLIR’s exclusive MSX® imaging blends visible and thermal images for more detailed imagery that is easier to understand.
Specifications| IMAGING & OPTICAL DATA | |
| IR Resolution | 80x60 pixels |
| Thermal Sensitivity / NETD | <0.10°C @ +30°C (+86°F) / 100mK |
| Field of View (FOV) | 48° x 37° |
| Focus | Fixed |
| DETECTOR DATA | |
| Detector Type | Focal Plane Array (FPA) Uncooled Microbolometer |
| Spectral Range | 7.3-13µm |
| VISUAL CAMERA | |
| Built-in Digtal Camera | 640x480 |
| Digital Camera FOV | Adapts to the IR lens |
| Sensitivity | Minimum 10 Lux without illuminator |
| MEASUREMENT | |
| Object Temperature Range | -10°C to +150°C (14°F to 302°F) |
| Accuracy | +/-2°C (+/-3.6°F) or +/-2% of reading (+10 to +100C@+10 to +35amb) |
| MEASUREMENT ANALYSIS | |
| Spotmeter | 6 |
| Area | 6 Boxes with max. / min. / average |
| Automatic Hot / Cold Detection | Max / Min temperature value and position shown within box |
| Measurement Presets | Yes |
| Atmospheric Transmission Correction | Automatic, based on inputs for distance, atmospheric temperature and relative humidity |
| Optics Transmission Correction | Automatic, based on signals from internal sensors |
| Emissivity Corrections | Variable from 0.01 to 1.0 |
| Reflected Apparent Temperature Correction | Automatic, based on input of reflected temperature |
| External Optics / Windows Correction | Automatic, based on input of optics / window transmission and temperature |
| Measurement Corrections | Global Object Parameters |
| ALARM | |
| Alarm Functions | Automatic alarms on any selected measurement function. A maximum of 5 alarms can be set |
| Alarm Output | Digital Out, store image, file sending (ftp), email (smtp), notification |
| SET-UP | |
| Color Palettes | Color palettes (BW, BW inv, Iron, Rain) |
| Set-up Commands | Data / Time, Temperature °C/°F |
| Web Interface | Yes |
| STORAGE OF IMAGES | |
| Storage Media | Built-in memory for internal storage |
| Image Storage Mode | IR, Visual, MSX |
| File Formats | Jpeg + FFF |
| ETHERNET | |
| Ethernet | Control, result and image |
| Ethernet Type | 100 Mbps |
| Ethernet Standard | IEEE 802.3 |
| Ethernet Connector Type | M12 8-pin X-coded |
| Ethernet Video Streaming | Yes |
| Ethernet Power | Power over Ehternet, PoE IEEE 802.3as class 0 |
| Ethernet Protocols | Ehternet/IP, Modbus TCP, TCP, UDP, SNTP, RTSP, RTP, HTTP, ICMP, IGMP, SFTP, SMTP, SMB (CIFS), DHCP, MDNS (Bonjour) |
| MARINE ELECTRONICS INTERFACE | |
| Multifunction Displays | Network compatible with Raymarine LightHouse II multifunction displays |
| IMAGE STREAMING | |
| Image Streaming Formats | Motion JPEG, MPEG, H.264 |
| Image Streaming Resolution | 640x480 |
| Image Modes | Thermal, Visual, MSX (IR-image with enhanced detail presentation) |
| Automatic Image Adjustment | Continuous |
| POWER SYSTEM (POE Injector) | |
| External Power Operations | 12/24VDC, 2W continuously / 3.1W absolute max |
| External Power Connector | Screw Connection (12V/0V/Chassis) |
| Voltage Allowed Range | 9-36VDC |
| ENVIRONMENT DATA | |
| Operating Temperature Range | 0°C to +50°C (32°F to +122°F) |
| Storage Temperature Range | —40°C to +70°C (—40°F to +158°F) IEC 68-2-1 and IEC 68-2-2 |
| Humidity (Operating and Storage) | IEC 60068-2-30/24 h 95% relative humidity +25°C to +40°C (+77°F to +104°F)/ 2 cycles |
| Encapsulation | IP67 (IEC 60529) |
